SilverStone Fortress FT02 90 Degree Motherboard Case

Article Index:

This is not Silverstones first or second attempt at making a 90 degree case. They first started off with the Raven and then with the Raven 2. If you know about the successful Fortress series then you know about the style it possesses. Now visualize that you combine the two this is where the Fortress FT02 comes in.

Sponsor: SilverStone

[hr]

First Impression

Silverstone FT02 CaseSilverstone FT02 Case

  Simple and clean is the look of the Silverstone Fortress 2. It’s clean lines and lack of other distractions make you look at the case. But once you start to dig deeper into the case you will begin to find more and more cool stuff from this mid tower class case.

Silverstone FT02 Case

Special Features

Revolutionary 90 degree motherboard mounting from RAVEN RV01

Innovative 4.5mm aluminum unibody frame from Temjin TJ07

Three 180mm fans for unprecedented positive pressure and stack effect cooling

Supports liquid cooling radiator mounting

Motherboard back plate opening behind CPU area for quick cooler assembly

Supports 11” wide ATX motherboard

Foam padded interior for advanced noise absorption

Specifications

Model No.

SST-FT02B (black)
SST-FT02S (silver)
SST-FT02B-W (black + window)
SST-FT02S-W (silver + window)

Material
4.5mm aluminum unibody frame, 0.8mm steel body

Motherboard
SSI CEB, ATX (maximum 12” x 11”), Micro ATX

Cooling System
Top
1 x 120mm exhaust, 1200rpm, 19dBA

Bottom
3 x 180mm intake fan 700/1000rpm, 18/27dBA

Expansion Slot 7

Front I/O Port

USB2.0 x 2
Audio x 1
MIC x 1

Power Supply
1 x Optional standard PS2 (ATX)

Expansion Card
Support 12” or 12.2” (with fan grille removed)

Dimension
212mm (W) x 497mm (H) x 616mm (D)

About Dewayne Carel

Dewyane began in the case modding scene when it was just starting out many years ago. He has created works for the likes of Cooler Master, ASUS, CPU Magazine, Razer, Zotac and more.
